| MODEL | VOLTAGE | NO LOAD | AT MAXIMUM EFFICIENCY | STALL | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
OPERATING RANGE |
NOMINAL | SPEED | CURRENT | SPEED | CURRENT | TORQUE | OUTPUT | EFF | CURRENT | TORQUE | |||
| rpm | A | rpm | A | g-cm | mN-m | W | % | A | g-cm | mN-m | |||
| ME-D-2431-01 | 4.5-9.6 | 4.5V CONSTANT | 16000 | 0.48 | 12706 | 2.27 | 82 | 8.08 | 10.75 | 67 | 10.40 | 461 | 45.20 |
| ME-D-2431-02 | 3.0-6.0 | 6.0V CONSTANT | 29000 | 0.80 | 24000 | 5.50 | 78 | 7.65 | 19.42 | 59 | 29.15 | 539 | 52.84 |
| ME-D-2431-03 | 12.0-24.0 | 15.0V CONSTANT | 9700 | 0.10 | 7500 | 0.52 | 62 | 6.08 | 4.90 | 62 | 2.64 | 336 | 32.94 |
| ME-D-2431-04 | 2.4-3.6 | 3.6V CONSTANT | 19000 | 1.00 | 16200 | 5.77 | 82 | 8.04 | 13.78 | 66 | 27.99 | 476 | 46.67 |
