BLDC 1625

Product category: Total BLDC motors of Hengdrive

Characteristic: CW & CCW, Signal function available, Locked rotor protection, Stepless speed regulation, Low noise, Low EMI, Long life 3000-30000hrs

Orders Are Welcome：+86-17875427185

Online Advisory

Detail


ME-B-1625

Output Power: 0.1W~4.0W

Weight: 23g (Approx.)

Brushless DC Motor-Typical Application

Communication Device: Antenna RCU

Automobile Parts: Micro Pump, Switcher

Home Application: White Goods, Small Appliance, Kitchen Appliance,

Smart Home, Micro Actuate

Medical Apparatus: Medical Pump, Liquid Pump, Gas Pump

Industry Equipment: Micro Pump, Micro Valve, Instrument, Meter

Business Equipment: Scanner, Cash Register

Personal Care: Skin Care, Beauty Apparatus

Model	Voltage(V)		No Load		Rated Load				Stall
Model	Operating Range	Rated	Speed (rpm)	Current (A)	Torque (mNm)	Speed (rpm)	Current (A)	Output P. (W)	Torque (mNm)	Current (A)
ME-B-1625-01	2-5	3.7	7500	0.145	0.687	5569	0.297	0.40	2.44	0.35
ME-B-1625-02	5-13	6	7800	0.050	0.687	6500	0.150	0.46	4.17	0.9
ME-B-1625-03	5-13	12	7850	0.034	0.687	6570	0.080	0.475	4.26	0.8
ME-B-1625-04	5-13	12	49265	0.314	0.687	47462	0.538	3.413	18.76	0.8
ME-B-1625-05	5-13	6	9995	0.082	1.001	8045	0.261	0.843	5.087	0.9
ME-B-1625-06	5-13	12	26600	0.118	1.501	22565	0.415	3.547	9.895	0.8

Characteristic: CW & CCW, Signal function available, Locked rotor protection, Stepless speed regulation, Low noise, Low EMI, Long life 3000-30000hrs

Notice: Data in this typical specification sheet are for other certain customer. Voltage, rated torque, speed, current, power and shaft extension feature & dimension can be changed to meet customer specific requirement.

Outline Drawing:
